SciAps Z901 Lithium Geo LIBS Handheld Analyzer

Introduction to SciAps Z901 Lithium Geo

The SciAps Z901 Lithium Geo LIBS Handheld Analyzer is a specialized analytical instrument developed for rapid lithium detection in geological and mining applications. This handheld device enables professionals to perform on-site elemental analysis with speed and confidence, supporting informed decision-making in exploration and resource evaluation.

Understanding LIBS Technology

What Is Laser-Induced Breakdown Spectroscopy

Laser-induced breakdown spectroscopy, commonly known as LIBS, is an analytical technique that uses a focused laser pulse to generate a plasma on the sample surface. The emitted light from the plasma reveals the elemental composition of the material.

Advantages of LIBS for Lithium Analysis

LIBS technology allows direct detection of light elements such as lithium, which are difficult to measure using conventional analytical methods. This capability makes LIBS especially valuable for mineral exploration and geochemical studies.

Key Features of SciAps Z901 Lithium Geo

Optimized for Lithium Detection

The Z901 Lithium Geo is engineered specifically for lithium-bearing minerals. Its calibration and spectral processing enable accurate lithium identification in a wide range of geological samples.

True Handheld Design

This analyzer features a compact and lightweight design that supports field mobility. Users can perform real-time analysis without transporting samples to a laboratory.

Fast and Reliable Results

The SciAps Z901 delivers immediate analytical feedback. Rapid results help geologists and mining professionals make decisions directly in the field.

Applications of SciAps Z901 Lithium Geo

Geological Exploration

Exploration teams use the Z901 Lithium Geo to locate lithium-rich formations. On-site analysis accelerates prospect evaluation and reduces exploration timelines.

Mining and Resource Development

Mining operations apply the analyzer to assess ore grades and support extraction planning. Real-time data improves efficiency and resource management.

Environmental and Research Applications

Researchers and environmental specialists use the device to study lithium distribution in soils and rocks. Portable analysis supports flexible field investigations.

Benefits of Using SciAps Z901 LIBS Analyzer

Increased Field Productivity

On-site lithium analysis eliminates delays associated with laboratory testing. Teams can cover more ground and evaluate samples faster.

Improved Decision Accuracy

Immediate elemental data supports informed decisions during exploration and mining activities. Accurate measurements reduce uncertainty in early-stage assessments.

Reduced Operational Costs

By minimizing laboratory analysis and sample transport, the Z901 Lithium Geo helps lower overall project costs.

Why Choose SciAps Z901 Lithium Geo

Professionals choose the SciAps Z901 Lithium Geo LIBS Handheld Analyzer for its precision, portability, and lithium-specific performance. The device supports modern exploration workflows that demand speed and reliable elemental data.

Exacting elemental analysis

Purpose-built handheld LIBS for measuring lithium in rocks and brines. Factory calibrated for lithium in pegmatite, clays and micas, including relevant base elements in the 350-675 nm range.

Intuitive operations

Android operating system and app-based software assure quality testing by every operator. Built-in Wi-Fi and Bluetooth, with GPS capability, allow users to print, email, and connect to virtually any information management system for full-featured reporting.
Automatically merge XRF and LIBS tests with SciAps Cloud Services, and easily manage operations from anywhere.

Designed for field and lab

SciAps LIBS series handheld analyzers, at just 3.5 lbs. (1.6 kg) with battery, have an internal camera for precise targeting of analysis locations; a macro camera for photo documentation of samples, reading bar codes and QR codes; a patented “sample sensor” that allows Class 1 operation (subject to LSO approval); high-resolution, rear facing display for easy viewing; rugged metal body for maximum durability; a tapered, narrow snout for difficult-to-access test locations; and user-replaceable argon that provides hundreds of tests at pennies per test. Pair with Profile Builder software for PC or tablet and achieve full benchtop functionality.

Specification:

Weight
3.87 lbs. (1.75 kg) with battery

Processing Electronics
ARM Quad Cortex -A53 1.2GHz memory: 2 GB LPDDR3, 16 GB eMMC

Calibration Check
316 stainless steel standard for automated calibration and wavelength scale validation.

Dimensions
10.75 x 2.375 x. 8.625 inches

Data Storage
Results storage: 32 GB SD card

Spectral Range
380 nm – 680 nm

Display
3.5-inch high-brightness color touchscreen, readable in all conditions. Rear-facing display for easy results viewing

Drift Correction
On-board automated drift correction software with factory-provided or user-provided reference materials.

Sample Viewing
Integrated camera and laser target indicator for viewing sample before and during analysis provide proper sample alignment. Includes second “macro camera” for scanning QR or bar codes and for photo-documentation and report generation.

Power
On-board rechargeable Li-ion battery, rechargeable inside device or with external charger, AC power.

Regulatory
CE, RoHS, USFDA registered. Class 3b laser. Sample sensor on board, allows for operation under Class 1 conditions subject to local LSO approval.

Warranty Information
3 Years
