Trimble R750 Radio Receiver

The Trimble R750 Radio Receiver is a high-performance GNSS receiver designed for accurate data transmission and real-time positioning in surveying, construction, and geospatial applications. In industries where precision, reliability, and connectivity are critical, the R750 ensures consistent signal reception and seamless communication across demanding work environments.

Introduction to Trimble R750 GNSS Radio Technology

Modern surveying and mapping projects rely on robust GNSS solutions for data accuracy. However, achieving real-time positioning often requires stable radio communication between receivers and base stations. For this reason, the Trimble R750 Radio Receiver combines advanced GNSS tracking with integrated radio technology to deliver reliable and efficient performance in field operations.

Purpose of GNSS Radio Receivers

GNSS radio receivers are used to receive real-time correction signals from base stations, allowing surveyors and engineers to achieve centimeter-level accuracy. As a result, projects such as topographic surveys, construction layouts, and infrastructure mapping benefit from precise positioning without post-processing delays.

Trimble Expertise in GNSS Solutions

Trimble is renowned for its innovations in positioning technology. Consequently, the R750 Radio Receiver integrates high-accuracy GNSS performance, long-range radio communication, and rugged design, providing field professionals with a dependable and user-friendly tool.

Key Features of Trimble R750 Radio Receiver

The R750 is engineered for professional users who demand accuracy, connectivity, and durability in the field.

High-Accuracy GNSS Performance

Accurate positioning is critical for quality surveys and construction projects. Therefore, the R750 ensures stable signal acquisition from multiple satellite constellations, improving precision even in challenging environments.

Integrated Long-Range Radio Communication

Real-time data transmission is essential for efficient workflows. As a result, the R750 features built-in long-range radio capabilities, allowing seamless communication with base stations and other field receivers.

Durable and Field-Ready Design

Surveying and construction environments are often harsh. Consequently, the R750 is designed with a rugged, water-resistant housing that withstands demanding conditions while maintaining reliable performance.

Applications of Trimble R750 Radio Receiver

The R750’s versatility allows it to support multiple professional applications, making it suitable for various industries.

Surveying and Mapping

Accurate land surveys require precise GNSS measurements. Therefore, the R750 is used in topographic surveys, boundary determination, and geospatial data collection for mapping purposes.

Construction Layout and Monitoring

Construction projects depend on precise positioning to ensure design compliance. Consequently, the R750 supports layout, monitoring, and alignment tasks, reducing errors and improving project efficiency.

Infrastructure and Utility Projects

Infrastructure projects rely on consistent real-time GNSS data. The R750 supports road construction, utility mapping, and asset management by delivering accurate positioning and immediate correction signals.

Benefits of Using Trimble R750 Radio Receiver

Organizations implementing the R750 gain operational advantages that improve efficiency, accuracy, and field workflow.

Reliable Real-Time Positioning

Integrated radio communication provides immediate corrections, ensuring high-precision results for critical projects.

Increased Productivity

Efficient data collection and real-time corrections reduce downtime, enabling teams to complete surveys and layouts faster.

Robust Field Performance

Durable construction ensures consistent operation in harsh environments, allowing uninterrupted inspection and measurement.

Trimble R750 GNSS Modular Receiver features

1. Multi-Constellation Support: Supports GPS, GLONASS, Galileo, BeiDou, QZSS, and SBAS, ensuring high accuracy and reliability in diverse conditions.
2. Trimble ProPoint GNSS Technology: Offers enhanced positioning accuracy and performance, particularly in challenging environments with obstructions such as trees, buildings, and rugged terrain.
3. Modular Design: Allows for flexible configurations and integration into various systems and applications. It can be used as a base station, rover, or network rover.
4. Enhanced RTK Performance: Provides robust Real-Time Kinematic (RTK) corrections for centimeter-level accuracy. It supports both single-baseline and network RTK solutions.
5. Scalable and Upgradable: Offers scalability with different hardware options and firmware upgrades to meet the evolving needs of users.
6. Connectivity: Equipped with various connectivity options, including Bluetooth, Wi-Fi, Ethernet, and serial ports, for seamless data transfer and remote management.

Trimble R750 GNSS specifications

GNSS Characteristics

– Channels: 672
– Satellite Tracking:
* GPS: L1 C/A, L2C, L2E, L5
* GLONASS: L1 C/A, L1P, L2C/A, L2P, L3
* Galileo: E1, E5a, E5b, E5 AltBOC, E6
* BeiDou: B1, B2, B3
* QZSS: L1 C/A, L1C, L2C, L5, L6
* SBAS: L1, L5

Trimble R750 GNSS Performance Specifications

– Real-Time Kinematic (RTK):
* Horizontal Accuracy: 8 mm + 1 ppm RMS
* Vertical Accuracy: 15 mm + 1 ppm RMS
– Static and Fast Static:
* Horizontal Accuracy: 3 mm + 0.1 ppm RMS
* Vertical Accuracy: 3.5 mm + 0.4 ppm RMS
– PPK (Post-Processed Kinematic):
* Horizontal Accuracy: 8 mm + 1 ppm RMS
* Vertical Accuracy: 15 mm + 1 ppm RMS

Communication and Data Logging

– Communication Ports:
* 2 x Serial Ports (RS232)
* 2 x Ethernet Ports (RJ45)
* 1 x USB Port
– Wireless Connectivity:
* Bluetooth
* Wi-Fi (802.11 b/g/n)
– Data Logging:
* Internal Memory: 32 GB
* External Memory Support: USB flash drives

Power and Environmental

– Power Consumption:
* Typical: 4.5 W
* Maximum: 6.0 W
– Input Voltage: 9 to 30 V DC
– Battery Life: Up to 10 hours with internal battery (depending on usage)
– Operating Temperature: -40°C to +65°C (-40°F to +149°F)
– Storage Temperature: -55°C to +85°C (-67°F to +185°F)
– Humidity: 100% condensing
– Shock and Vibration:
* Shock: MIL-STD-810G
* Vibration: MIL-STD-810G

Warranty Information
3 Years
