EVIDENT IPLEX NX Flexible Videoscope

The EVIDENT IPLEX NX Flexible Videoscope is an advanced inspection solution designed to support precise visual inspection in complex and hard-to-reach areas. In modern industrial environments, reliable inspection tools are essential. Therefore, this flexible videoscope helps professionals improve inspection accuracy, reduce downtime, and maintain asset integrity.

Introduction to EVIDENT IPLEX NX Technology

Visual inspection often requires access to confined or intricate spaces. However, traditional inspection methods can be limited in both reach and clarity. For this reason, the EVIDENT IPLEX NX Flexible Videoscope combines advanced imaging technology with flexible maneuverability to meet demanding inspection requirements.

Purpose of Flexible Videoscope Inspection

The primary purpose of a flexible videoscope is to provide clear visual access to areas that are otherwise inaccessible. As a result, inspectors can identify defects, corrosion, or wear without disassembling equipment. Moreover, this approach supports preventive maintenance strategies.

EVIDENT’s Approach to Industrial Inspection

EVIDENT focuses on developing inspection solutions that balance performance and practicality. Consequently, the IPLEX NX Flexible Videoscope reflects this approach by offering robust imaging capabilities while remaining adaptable to various inspection environments.

Key Features of the EVIDENT IPLEX NX Flexible Videoscope

The IPLEX NX is engineered to deliver consistent performance across different inspection scenarios. In addition, its design prioritizes image quality, durability, and ease of use.

High-Quality Imaging Performance

Clear visualization is critical for accurate inspection. Therefore, the EVIDENT IPLEX NX Flexible Videoscope provides high-resolution imaging that enables inspectors to detect fine details. Furthermore, enhanced image clarity improves diagnostic confidence.

Flexible and Responsive Insertion Tube

Maneuverability is essential when navigating complex internal structures. For this reason, the flexible insertion tube of the IPLEX NX allows smooth movement through curved and narrow pathways. As a result, inspections can be completed more efficiently.

Durable Design for Industrial Use

Inspection environments can be demanding. Consequently, the EVIDENT IPLEX NX Flexible Videoscope is designed to withstand harsh conditions. Moreover, its durable construction supports long-term reliability in industrial applications.

Applications of EVIDENT IPLEX NX Flexible Videoscope

The versatility of the IPLEX NX makes it suitable for a wide range of industries. Therefore, it is widely used in inspections that require precision and adaptability.

Power Generation and Energy Sector

In power generation facilities, routine inspection is essential for operational reliability. As a result, the IPLEX NX Flexible Videoscope helps inspectors assess internal components of turbines, boilers, and pipelines efficiently.

Manufacturing and Industrial Maintenance

Manufacturing operations rely on consistent equipment performance. Therefore, this videoscope supports inspection of machinery, internal assemblies, and production lines. Moreover, early detection of issues helps reduce unplanned downtime.

Aerospace and Transportation

In aerospace and transportation industries, safety and compliance are critical. Consequently, the EVIDENT IPLEX NX Flexible Videoscope assists in inspecting engines, structural components, and mechanical systems without extensive disassembly.

Benefits of Using EVIDENT IPLEX NX Flexible Videoscope

Organizations that use the IPLEX NX gain practical and operational advantages. In addition, these benefits support inspection efficiency and cost control.

Improved Inspection Efficiency

Faster and clearer inspections save time. Therefore, the IPLEX NX Flexible Videoscope allows professionals to complete inspections more efficiently. As a result, maintenance schedules can be optimized.

Reduced Maintenance Costs

Non-destructive inspection reduces the need for disassembly. Consequently, maintenance costs and downtime are minimized. Moreover, this approach supports better resource allocation.

Enhanced Inspection Confidence

Accurate visual data supports confident decision-making. Furthermore, consistent image quality helps inspectors document findings and plan corrective actions effectively.

Measure with Confidence Using 3D Modeling

Choosing the right measurement point is now even easier.
3D modeling enables you to see the details of what you’re inspecting from multiple angles, making it easier to specify the exact location of your measurement points.

Instantly Confirm Measurement Objects

3D modeling enables you to clearly see the shape and complexity of your target
Precisely designate your measurement points for faster inspections
Choose the right points the first time to minimize the need to re-measure

Set Reference Lines Where You Want Them

3D images facilitate reliable reference lines on difficult components, such as the edge of a turbine blade
Reduce the chance of misalignment

Make Confident Depth Measurements

Confirming the reference plane is intuitive
Specify your measurement points with confidence for reliable depth measurements

Our Highest Quality Images

The IPLEX NX videoscope delivers crisp, high-resolution images.
Its reliable image quality increases your probability of detection, helping you make clear decisions and maintain crucial systems.

Specifications:

SCOPE UNIT

Insertion tube
– Scope diameter: Φ6.0 mm
– Scope length: 7.5 m
– Exterior: High – durability tungsten braid
– Tube flexibility: TaperedFlex tube with flexibility gradually increasing toward the distal end

Optical system
– Field of view: Selectable by optical adaptor. Adaptor for Stereo measurement attachable
– Direction of view: Selectable by optical adaptor. Adaptor for Stereo measurement attachable

Illumination
– High – intensity laser diode

Articulation section
– Articulation angle Up/Down/Right/Left: 150°
– Articulation operation: 128 mm × 203 mm × 110 mm (4.9 in. × 8 in. × 4.3 in.)

BASE UNIT;

– Dimensions (W x H x D): 320 mm x 310 mm x 180 mm
– Approx. system weight (with battery and SDHC card): 7.6 kg
– LCD monitor: 8.4-inch daylight-view, touch screen LCD, clear type
– Input terminal: S-Video
– Output terminal: VGA
– USB connector: Type A connector, Version 2.0 standards
– Power supply: Battery: 14.8 V nominal, approx. 100-minute operating time.
AC power: 100 V to 240 V, 50/60 Hz (with supplied AC adaptor)
– Recording media: SDHC card and USB flash memory(Still image recording only)

Still image recording
– Resolution: H1024 x V768 (Pixel)
– Recording format: Compressed JPEG format

Video recording
– Resolution: H1024 x V768 (Pixel)
– Recording format: MPEG-4 AVC (H.264) format, Windows Media Player compatible

Stereo measurement
– Distance: Distance between two points
– Point-to-line: Perpendicular distance between a point and a user-defined line
– Depth: Orthogonal depth/height distance between a point and a user-defined plane
– Area/Lines: Multiple point circumference and area measurement

3D Modeling: Live cross section, X/Y/Z-axis rotation, 2x Color mapping mode

Scalar measurement: Distance between two points based on a known measurement in the same plane

Package Includes:

– Olympus IPLEX NX IV9675N
– Probe: Insertion tube 6.0mm diameter, 7.5m length
– MAJ-2260 Remote Control Unit
– LCD cable short
– LCD Cable long
– MAJ-1253 (for 6.0 mm insertion tube) Rigid Sleeve Set
– 2x NP-L7S Lithium-ion Battery
– JL-2PLUS Battery Charger
– AT80D/FF-IV96N IPLEX TIP
– AT120D/NF-IV96N IPLEX TIP
– AT120D/FF-IV96N IPLEX TIP
– AT120S/NF-IV96N IPLEX TIP
– AT120S/FF-IV96N IPLEX TIP
– AT90D/90D-IV96N IPLEX TIP
– Protective box for optical adapters
– SDHC Card 4 GB
– Cleaning kit
– Attachment strap for the probe
– 2x Carry Case
– Warranty Card
– Calibration Certificate

Warranty Information
3 Years
