Waygate Everest Mentor Flex VideoProbe
Introduction to the Waygate Everest Mentor Flex VideoProbe
The Waygate Everest Mentor Flex VideoProbe is a high-performance industrial video borescope designed for advanced remote visual inspection (RVI) applications across aviation, power generation, oil & gas, manufacturing, automotive, and industrial maintenance industries.
Developed by Waygate Technologies, the Everest Mentor Flex combines rugged military-grade durability, advanced articulation control, high-quality imaging, 3D measurement capability, and intuitive touchscreen operation into a portable inspection platform.
The system is engineered to help inspectors detect defects faster, improve inspection accuracy, reduce downtime, and streamline digital reporting workflows in harsh industrial environments.
Why Choose the Everest Mentor Flex VideoProbe
Advanced Remote Visual Inspection Performance
The Mentor Flex provides high-resolution visual inspection for hard-to-reach internal components without disassembly.
Rugged Industrial Durability
The system features a military-grade magnesium housing and reinforced insertion tubes designed for harsh field environments.
Precision Articulation Control
High-powered steering motors enable smooth and responsive probe articulation for navigating complex inspection paths.
High-Quality Imaging Technology
TrueSight™ image processing improves visibility, contrast, brightness, and defect detection performance.
Portable and Ergonomic Design
The lightweight handheld configuration improves mobility and operator comfort during extended inspections.
Key Features of the Everest Mentor Flex
TrueSight™ Imaging Technology
The integrated imaging system enhances visual inspection clarity and defect recognition.
Imaging Features
- Dark Boost image enhancement
- Distortion correction
- Color saturation optimization
- Digital zoom
- Long exposure imaging
- Real-time video streaming
All-Way Probe Articulation
The All-Way articulation system enables precise navigation through difficult internal pathways.
Benefits
- Faster inspections
- Improved maneuverability
- Easier access to hidden areas
- Better defect visibility
- Reduced inspection time
Real3D™ Stereo Measurement
Optional Real3D™ stereo measurement technology generates accurate 3D point cloud measurements.
Measurement Capabilities
- Crack depth measurement
- Pit analysis
- Defect sizing
- Surface profiling
- Distance-to-target measurement
Menu Directed Inspection (MDI)
MDI software guides inspectors through digital inspection workflows.
Workflow Advantages
- Automated file naming
- Smart tagging
- Automatic report generation
- Reduced documentation errors
- Faster reporting
Applications of Everest Mentor Flex VideoProbe
Aviation Maintenance
Widely used for:
- Turbine blade inspection
- Combustion chamber inspection
- Aircraft engine maintenance
- FOD detection
- Internal structural inspection
Power Generation
Supports inspection of:
- Gas turbines
- Steam turbines
- Heat exchangers
- Boilers
- Generators
Oil and Gas Industry
Used for:
- Pipeline inspection
- Pressure vessel inspection
- Refinery maintenance
- Offshore equipment inspection
- Corrosion monitoring
Automotive and Manufacturing
Ideal for:
- Engine inspection
- Weld inspection
- Mold verification
- Gearbox inspection
- Quality control
Industrial Maintenance
Supports:
- Remote visual inspection
- Internal cavity analysis
- Structural inspection
- Preventive maintenance
- Failure analysis
Waygate Everest Mentor Flex Technical Specifications
General Specifications
| Specification | Details |
|---|---|
| Product Name | Waygate Everest Mentor Flex VideoProbe |
| Product Type | Industrial Video Borescope |
| Manufacturer | Waygate Technologies |
| Inspection Method | Remote Visual Inspection (RVI) |
| Operation Type | Portable Handheld |
| Housing Material | Magnesium Alloy & Polycarbonate |
| Probe Housing | Titanium |
| Inspection Technology | VideoProbe |
| Display Type | Multi-touch WXGA LCD |
| Internal Storage | 32 GB |
| Wireless Connectivity | Wi-Fi |
| Video Output | HDMI |
| USB Ports | Dual USB Host Ports |
| Protection Rating | IP65 |
Display and User Interface Specifications
| Specification | Details |
|---|---|
| Screen Size | 5.8-inch |
| Display Technology | TFT WXGA AWV LCD |
| Touchscreen Type | Gorilla® Glass Multi-touch |
| Daylight Readability | Yes |
| User Interface | Touchscreen + Joystick |
| Digital Zoom | 5x Continuous |
| Annotation Tools | Text & Graphic |
| Gesture Control | Pinch, Swipe, Pan |
Camera Specifications
| Specification | Details |
|---|---|
| Image Sensor Type | SUPER HAD™ CCD |
| Pixel Resolution | 440,000 Pixels |
| Camera Housing | Titanium |
| Imaging Modes | Real-Time Video & Still Capture |
| White Balance | Automatic & User Defined |
| Exposure Control | Automatic & Manual |
| Long Exposure | Up to 16 Seconds |
| Lighting Type | White LED |
Probe Diameter Options
| Probe Diameter | Applications |
|---|---|
| 3.9 mm | Small access inspections |
| 4.0 mm | Tight industrial pathways |
| 6.1 mm | General industrial inspection |
| 8.4 mm | Large cavity inspections |
Probe Length Options
| Probe Diameter | Available Lengths |
|---|---|
| 3.9 mm / 4.0 mm | 2.0 m, 3.0 m |
| 6.1 mm | 2.0 m to 8.0 m |
| 8.4 mm | 2.0 m to 10.0 m |
| Extended Options | Up to 300 m Available |
Articulation Specifications
| Specification | Details |
|---|---|
| Articulation Type | All-Way® |
| Steering Mechanism | High-Power Servo Motors |
| 2m–4.5m Probe Articulation | ≥160° All Directions |
| 6m–10m Probe Articulation | ≥140° All Directions |
| Articulation Lock | Supported |
| Probe Center Reset | Supported |
Environmental Specifications
| Specification | Details |
|---|---|
| Probe Operating Temperature | -25°C to +100°C |
| System Operating Temperature | -20°C to +46°C |
| Storage Temperature | -25°C to +60°C |
| Relative Humidity | 95% Max Non-Condensing |
| Waterproof Rating | 1 Bar / 10.2 m Water Depth |
| Dust Protection | Yes |
| Rugged Testing | MIL-STD Certified |
Battery and Power Specifications
| Specification | Details |
|---|---|
| Battery Type | Lithium-Ion |
| Battery Runtime | Approximately 3 Hours |
| Battery Voltage | 10.8V |
| Battery Capacity | 73 Wh / 6.8 Ah |
| AC Input | 100–240 VAC |
| DC Input | 18V DC |
Connectivity Specifications
| Specification | Details |
|---|---|
| Wi-Fi Standard | 802.11 a/b/g/n |
| Wireless Streaming | Supported |
| HDMI Output | Yes |
| USB Ports | 2× USB 2.0 |
| Mobile Device Integration | Supported |
| InspectionWorks Connect | Supported |
File and Media Specifications
| Specification | Details |
|---|---|
| Image Format | JPEG (.JPG) |
| Video Format | MPEG4 AVC / H.264 |
| Video Frame Rate | Up to 60 fps |
| Internal File Manager | Embedded |
| Report Export | Word & PDF Compatible |
Optical Tip Specifications
Available Optical Configurations
| Optical Type | Available Options |
|---|---|
| Forward View | Multiple FOV Configurations |
| Side View | Supported |
| Stereo Measurement | Real3D™ Options |
| Wide Angle | Available |
| Long Depth of Field | Available |
Field of View Options
| Lens Type | FOV Range |
|---|---|
| Narrow Focus | 40° |
| Standard | 50°–90° |
| Wide Angle | 115°–120° |
Software Features
Embedded Inspection Software
The Mentor Flex includes advanced onboard inspection software for streamlined workflows.
Software Functions
- Smart file management
- Inspection guidance
- Automated reporting
- Image enhancement
- Defect annotation
- Wireless file transfer
Advantages of the Everest Mentor Flex
Faster Inspections
Responsive articulation and advanced imaging reduce overall inspection time.
Improved Defect Detection
TrueSight™ imaging increases visibility of cracks, corrosion, pitting, and other defects.
Rugged Industrial Reliability
Designed for harsh industrial environments with military-grade durability.
Flexible Probe Configurations
Multiple probe diameters and lengths allow adaptation to various inspection tasks.
Efficient Digital Reporting
Integrated MDI software automates inspection documentation and reporting.
