X-MET 8000 Handheld XRF Analyzer: Fast and Accurate Material Analysis
The X-MET 8000 range of handheld X-ray fluorescence (HHXRF) analyzers is designed for rapid alloy identification and precise elemental analysis across a wide variety of materials, including metals, polymers, wood, solutions, soil, ores, and minerals. Rugged, user-friendly, and practical, the X-MET 8000 delivers trustworthy results wherever you need them.
Why Choose the X-MET 8000
High-Speed and Accurate Material Testing
With advanced large-area SDD detectors and optional small-spot collimators, the X-MET 8000 provides precise measurements of elements from Mg to U, enabling reliable identification of alloys, metals, and other complex materials.
Rugged and Reliable
IP54-rated for dust and water resistance
Optional window shield protects the detector from damage
Works in environments with sample temperatures up to 100°C, or 400°C with the HERO™ heat-resistant window
Versatile and Flexible Models
The X-MET 8000 series offers multiple models to suit different applications and budgets, from routine alloy analysis to more advanced soil, mining, and industrial testing.
Key Features
X-ray tube: 40kV or 50kV
X-ray tube filters: Single or optional 6-position filter wheel for optimal element analysis
Detector: Large-area SDD
Maximum sample temperature: 100ºC (400ºC with optional HERO™ window)
IP54 rating for dust and water resistance
Optional integrated camera for accurate sample positioning
Optional small-spot collimator for precise measurement of small features
Standardless calibrations including light element analysis
Technical Specifications
| Specification | Details |
|---|---|
| Description | High-speed grade identification and analysis from aluminum to steels, bronzes, and brasses |
| X-ray tube | 40 kV or 50 kV (depending on application) |
| X-ray tube filters | 6-position filter wheel for elements Mg–U |
| Detector | Large-area SDD |
| Elemental Range | Mg – U |
| Max Sample Temperature | 100ºC standard, 400ºC with HERO™ heat-resistant window |
| IP Rating | IP54 |
| Weight | 1.5 kg |
| Battery Life | 10–12 hours |
| Detector Protection | Optional window shield |
| Calibrations | Standardless (includes light elements) |
Package Contents
X-MET 8000 Optimum analyzer
Check sample
Soil and mining CRMs (as per package), blank check sample
Battery charger with UK, US, Euro, and Australia plug adapters
Two Li-ion batteries
USB cable
USB memory stick with User Manual and Safety Manual in 13 languages
Light radiation shield
Background plate
WiFi and Bluetooth connectivity
Hard carrying case
Warranty card and calibration certificate
Warranty Information
The X-MET 8000 comes with a 3-year warranty, ensuring long-term reliability and support.
