Rigaku KT100S Series Handheld LIBS Analyzer

KT-100S Handheld LIBS Analyzer: Advanced Alloy Identification for Industrial Applications

Introduction to the KT-100S

The KT-100S handheld LIBS analyzer represents the next generation of portable metal analysis. Built with high-performance miniature spectrometers and advanced laser technology, it offers fast, precise, and reliable alloy identification for a wide range of industrial environments. Its rugged design, lightweight form, and improved analytical capabilities make it a preferred tool for professionals in scrap recycling, fabrication, aerospace, petrochemical, and quality assurance operations.

Key Applications of the KT-100S

1. Scrap Metal Sorting

The KT-100S provides rapid and accurate alloy identification, helping scrap facilities classify metals efficiently and maximize recovery value.

2. Quality Assurance in Metal Fabrication

Fabricators rely on the analyzer to confirm incoming materials and verify alloy specifications before production.

3. Positive Material Identification (PMI)

In mission-critical industries—such as aerospace, energy, and petrochemical—the KT-100S supports fast PMI checks to ensure compliance and prevent costly material mix-ups.

Advantages of the KT-100S Handheld LIBS Analyzer

Compact, Lightweight, and Efficient

Engineered for All-Day Use

The KT-100S is small and lightweight, reducing user fatigue and enabling high-volume testing without discomfort. Its compact shape also allows easy portability between field locations.

Built for Harsh Industrial Environments

MIL-STD-810G Certified Durability

The analyzer meets the rigorous U.S. Military Standard 810-G, demonstrating resistance to:

• Vibration

• Shock

• Drop impact

IP-54 Environmental Protection

The IP-54 rating ensures resistance to dust, debris, and splashing water—ideal for scrap yards, foundries, and outdoor job sites.

Lower Cost of Ownership

Unlike older analyzer technologies that require complex licensing or high maintenance, the KT-100S offers reduced regulatory requirements and lower long-term operating costs.

Advanced Light Element Detection

Superior LIBS Sensitivity

LIBS technology excels at identifying light elements such as:

• Aluminum (Al)

• Magnesium (Mg)

• Beryllium (Be)

Historically, reliable LIBS analysis of these elements was only possible in laboratory environments. The KT-100S changes that by utilizing innovations in laser power and spectrometer miniaturization, enabling accurate field-based identification.

Precise Alloy Identification

The analyzer easily distinguishes:

• Popular aluminum grades: 1100, 6061, 6063

• Al-Si brasses and bronzes

• Beryllium in copper alloys

This expanded capability supports industries where light-element precision is critical.

Durability and Versatility in Real-World Use

Performance in Harsh Conditions

The KT-100S withstands rough handling and extreme conditions, making it a dependable choice for:

• Scrap metal yards

• Outdoor inspections

• Remote industrial sites

Enhanced Protection Systems

• Military-grade durability

• Safety window shielding

• IP-54 ingress protection

These features significantly reduce downtime and maintenance costs.

Ergonomic and User-Focused Design

Optimized for One-Handed Operation

Pistol-Grip Design

The ergonomic pistol shape allows comfortable one-handed control, with raised buttons and quick-launch triggers positioned for easy access.

Tiltable High-Visibility Display

• 3.5” high-resolution screen

• Adjustable angle for viewing in bright sunlight or confined spaces

Portable and Convenient

The compact body includes a built-in kickstand, allowing quick placement and easy grab-and-go usability.

QuickID Software for Fast Alloy Grading

Simple Match/No Match System

QuickID software provides:

• Rapid matrix selection

• Alloy grade identification

• Real-time elemental composition percentages

The intuitive display simplifies decision-making, even for new users.

Customizable Alloy Library

Users can add new alloys to the on-board library, tailoring the analyzer to their specific workflow.

Data Management and Connectivity

• On-board camera for sample photos

• USB and WiFi data transfer

• Password protection and auto-sleep mode

These features improve traceability, security, and reporting efficiency.

Drill Down Sample Preparation Technology

Automatic Surface Cleaning for Accurate Readings

Industrial metals often contain:

• Dirt

• Oxidation

• Coatings

The KT-100S uses a patented Drill Down function that automatically burns through surface imperfections to expose clean metal for precise analysis. This feature significantly enhances accuracy in challenging field conditions.

KT-100S Technical Specifications

Physical Design

• Pistol-shaped body: 24.3 cm

• Dimensions: 9.55” L × 3.30” W × 10.10” H

• Weight: ~1.5 kg (3.25 lbs)

Display

• 3.5” high-resolution tiltable screen

Environmental Ratings

• IP-54 rated for dust and moisture resistance

• MIL-STD-810G certified ruggedness

• Operating temperature: 5°C to 40°C

Laser System

• Proprietary 1064 nm Class 3B laser

• Low ocular safety distance (NOCD)

Certifications

• FDA 1040

• CE Certified

• ISO 9001:2008 manufacturing

Power & Battery

• External battery charger (100–240 VAC)

• Includes multiple lithium-ion batteries

Warranty

• 36-month warranty

Package Contents

The KT-100S package includes:

• KT-100S handheld analyzer

• Charging dock for battery and device

• User manual

• (2) Lithium-ion batteries

• Integrated camera

• Hard carrying case

• Online training access

• Calibration certificate

• 3-year warranty
